Quality Control System
Txhua lub tshuab CNC tshuab yog tsim nyob rau hauv cov txheej txheem kev tswj xyuas zoo uas suav nrog kev ua haujlwm, kev sib dhos, kev sim, thiab kev soj ntsuam zaum kawg.
Incoming Material Inspection (IQC)
Ua ntej pib tsim khoom, tag nrho cov khoom siv raw thiab cov khoom raug tshuaj xyuas.
Cov khoom soj ntsuam muaj xws li:
● Cam khwb cia hlau qauv zoo thiab kev ntxhov siab sab hauv
●Ball screws thiab linear qhia qhov tseeb qib
●Spindle runout kam rau ua pov thawj
●Electrical Cheebtsam hom thiab specification check
Lub hom phiaj:
Xyuas kom tsuas yog cov khoom tsim nyog nkag mus rau hauv cov txheej txheem tsim khoom.
Machining Process Inspection (IPQC)
Thaum lub sij hawm machining ntawm lub tshuab Cheebtsam
Kev tshuaj xyuas muaj xws li:
Qhia rail installation flatness
Screw alignment raug
Structure machining kam rau ua pov thawj
Machined nto zoo tswj
Cov cuab yeej siv:
Precision ntsuas ntsuas
Dial ntsuas
Laser alignment cov cuab yeej (rau cov khoom tseem ceeb)
Tshuab Kev Tshawb Fawb
Thaum lub sij hawm sib dhos, txhua qhov subsystem raug kuaj xyuas:
Mechanical Assembly:
Lub txaj thiab kab sib dhos
Axis txav smoothness
Lubrication system installation
Hluav taws xob sib dhos:
Kev txheeb xyuas cov kab hluav taws xob
Tswj system installation
Kev ntsuas kev nyab xeeb interlock
Tshuab khiav Test
Txhua lub tshuab raug kuaj tsis tu ncua ua ntej ua zaub mov xa tuaj.
Standard xeem ntev
24 mus rau 72 teev nyob ntawm seb hom tshuab
Test cov ntsiab lus
Nruam axis txav mus kuaj
Tool hloov lub voj voog kuaj
Spindle load ua haujlwm kuaj
Thermal stability xyuas
Lub hom phiaj
Txhawm rau txheeb xyuas kev ruaj ntseg raws li kev ua haujlwm tiag tiag.
Kev tshuaj xyuas qhov tseeb ua ntej xa khoom xa tuaj
Kev tshuaj ntsuam zaum kawg suav nrog:
Cov txiaj ntsig tshuaj ntsuam tuaj yeem sau thiab muab tau raws li qhov kev thov.
Positioning raug kuaj
1
>>
Kev ntsuam xyuas qhov tseeb
2
>>
Circular interpolation test (rau CNC kev ua tau zoo)
3
>>
Surface machining sim (yog tias xav tau los ntawm cov neeg siv khoom)
4
Cov ntaub ntawv thiab cov ntaub ntawv zoo
Peb tuaj yeem muab:
● Daim ntawv tshuaj ntsuam xyuas tshuab
● Sib sau ua pov thawj daim ntawv qhia
●Test run summary
● Cov ntaub ntawv ua raws CE
Cov ntaub ntawv no txhawb cov neeg siv khoom zoo hauv kev tshawb xyuas thiab cov kev xav tau ntshuam.
